xi
P7F-M WS specications summary
Model Name P7F-M WS
Processor Support / System Bus
1 * Socket LGA1156
Quad Core Intel Xeon 3400 series Server
Processor
Quad Core Intel Core i7-800 series Desktop
Processor
Quad Core Intel Core i5-700 series Desktop
Processor
Dual Core 32nm CPU design Ready
Core Logic
Intel
®
3420 PCH
Form Factor
mATX, 9.6" * 9.6"
ASUS Features Fan Speed Control
V
Rack Ready (Rack and
Pedestal dual use)
V
Memory Total Slots
4 (RDIMM/UDIMM)
Capacity
Maximum up to 32GB (RDIMM)
Maximum up to 16GB (UDIMM)
Desktop Processor do not support RDIMM &
ECC UDIMM
Memory Type
DDR3 800/1066/1333 Reg DIMM / Unbuffered
DIMM with ECC/ non ECC
Memory Size
1 GB, 2GB, 4GB, 8GB (RDIMM)
1 GB, 2GB, 4GB (UDIMM)
Expansion Slots
(follow SSI
Loacation #)
Total PCI/PCI-X/PCI-E
Slots
4
Slot Loacation 4
1 * PCI 32bit/33 MHz
Slot Loacation 5
1 * PCI 32bit/33 MHz
Slot Loacation 6
1 * PCI-E x16 (Gen2 x16 Link)
Slot Loacation 7
1 * PCI-E x8 (x4 Link) or MIO support
Storage SATA Controller
Intel
®
3420:
6* SATA2 300MB/s ports-
Intel Matrix Storage utility supports software
RAID 0, 1, 10 & 5 (Windows)
Networking LAN
2 * Intel 82574L
Onboard I/O
Connectors
PSU Connector
24-pin ATX power connector + 8-pin ATX 12V
power connector (24-pin + 4-pin power supply
supported)
USB Connectors
2 (support 4 USB port)
Fan Header
5* 4pin
TPM header
20-1 pin TPM header
Refer to
2.3 Central Processing Unit
for more information on CPU.
